EVERES UNO, DLP 3D printer using resin polymerization by means of light projection.
Fast & accurate
The patent pending ZTT (Zero Tilting Technology) enables extremely fast printing routines with uncompromising quality. The PTFE bottom of the vat is not subject to degeneration during the photo-curing process of the resin. The first layer will be precise and detailed as the last. The mechanical stress in the formation of the object is minimal.
The alignment and zeroing of the building platform take place automatically for every print job, without the need for any manual intervention, thus limiting any possible human error.
The resin cartridge types are automatically recognized by Tag RFID; the resin loading/unloading operations are automatically managed at the start and at the end of every single printing process.
|Building area||124.8 x 70.2 mm|
|Z axis||200 mm|
|XY resolution||65 micron|
|Light source||UV LED@405 nm|
|Projector technology||DLP FullHD 1920 × 1080 px|
|Layer thickness range||Min 25 micron - Max 150 micron|
|Printing speed||up to 6 min/cm|
|Dimensions||411 mm Ø (base) x 870 mm H x 272 mm Ø (top)|
|Network 3D printer||Yes (Ethernet 10/100/1000 - WiFi)|
|SBP: Smart Building Platform||Sì|
|ZTT: Zero Tilting Technology||Sì|
|Electrical input||100/240 V AC - 50/60 Hz|
|Electrical output||24V DC con alimentatore|
|High Adhesion SBP||Optional|
