MCL, laser cutting system in the axis version on recirculating ball screw.
MCL is able to offer high performance and functionality with a stable performance over time: the structure is made of electro-welded tubular steel with thermal stress relieving.
The cutting head incorporates a capacitive anti-collision sensor that ensures high-precision machining at all times: MCL offers superior performance in terms of speed and cutting quality, ensuring perfect cutting results even with continuous changes in direction and acceleration variations.
MCL is intended to be an ideal basis for combined processes, offering the possibility of associating other types of machining such as laser marking or milling to laser cutting.
Contact us for more information.
|Model||MCL 300/3000||MCL 500||MCL 1000|
|Output power||300/3000 W||500 W||1000 W|
|Power supply||230V 50/60Hz 1ph|
|Overall power consumption||6 KW||7,5 KW||8,5 KW|
|Working area for cutting box version X, Y||340 x 350 mm|
|Max width with internal motorized plate dragger||max 120 mm|
|Max width with external pneumatic plate dragger||max 200 mm|
|Axis precision||0,025 +/- mm|
|Axis resolution||0,010 +/- mm|
|Axis max speed||30 m/min|
|Machine dimensions w x l x h||900 x 1470 x 2400 mm Without console (L+750 with console)|
|Cooling system dimensions w x l x h||600x600x1050 mm|
|Total weight||800 kg|
|Cooling system weight||80 kg|
